當前位置:首頁 > 產品中心

GGS-240(P15)液體灌裝機

該機是一種塑料瓶熱成型灌封設備,適用于制藥,農藥,化妝品,食品飲料,保健品等行業液體或膏體類物料的大批量灌裝。廣泛用于口服液,液體農藥和肥料,電子煙油,化妝品,食用油,飲料,液體保健品等物料的灌裝。
商品信息
性能及特點

1.HC 高速高精度高端運動控制器。無極變頻調速控制。伺服機控制。
2.人機界面裝置,伺服拉膜,換模具調整長短方便操作簡單。
3.自動放卷,卷膜分切和對折,有光電正反面圖案對版多功能。瓶子底部是平的,可直立,產品精美。
4.包裝材料耗損小利用率高達 95%-99%,節約包裝成本不受形狀限制。
5.采用電子蠕動泵裝置。調整方便,清洗簡單。
6.灌裝精度正確。灌裝回吸功能,不滴漏。
7.與藥接觸的部位采用優質不銹鋼 316L,機器外罩全部是SUS304不銹鋼。符合 GMP 標準 。

PERFORMANCE CHARACTERISTICS
1.High capacity, high speed, high precision, and advanced motion controller. Stepless frequency conversion speed regulation control. Servo motor control.
2.Human-machine interface. Servo film traction. The replacement of the mould and its length adjustment is convenient and easy to operate.
3.Automatic unwinding, roll film cutting and folding. It has positive and negative pattern alignment function with photoelectric device. As the bottom of the bottle is flat, it can stand. The product is exquisite and beautiful.
4.The use ratio of the packing material is as high as 95%-99%,which has small consumption. The packing cost is not restricted by the product shape, which helps to save cost.
5.It adopts electronic peristaltic pump device, which has convenient adjustment and simple cleaning.
6.High filling accuracy with suction back function without any dripping.
7.The parts contacting with the medicine adopthigh quality stainless steel 316L, and the outer cover of the machine is made of SUS304 stainless steel, which meets with GMP standard.


產品用途



該機是一種塑料瓶熱成型灌封設備,適用于制藥,農藥,化妝品,食品飲料,保健品等行業液體或膏體類物料的大批量灌裝。廣泛用于口服液,液體農藥和肥料,電子煙油,化妝品,食用油,飲料,液體保健品等物料的灌裝。

APPLISCATION
This machine is a plastic bottle thermoforming filling and sealing equipment, which is suitable for large-scale filling of liquid or paste materials in pharmaceutical, pesticide, cosmetic, food and beverage, health care products and other industries.It is widely used in the filling of oral liquid, liquid pesticides and fertilizers, electronic cigarette oil, cosmetics, edible oil, beverages, liquid health products and other materials.


主要技術參數

最大成型深度

Max. forming depth

12mm

成型次數

Forming frequency

25次/每小時22000支

包裝材料

Packing material

PET/PE,PVC/PE,PVE/EVOH

灌裝容量

Filling volume

1-100ml

電源總功率

Toal power supply power

22KW

電壓

Voltage

380V/50Hz

整機重量

Machine weight

3000Kg

外形尺寸(長x寬x高)

Overall dimension (L*W*H)

7300×1050×1800(mm)

前機身長2800×1050×1250(mm)

后機身長4500×1050×1800(mm)
